Screen USA TR3665

Description: 36 wide, 65' long track mounted, radial stacking conveyor ENGINE - 49HP Deutz 2.9 Tier 4 Final air-cooled diesel FRAME - Deep folded plate frame constructed with heavy-duty bracing for strength and stability. Hydraulic folding head section. IDLERS - 20 degree troughing on feed area - 35 degree - Flat return idlers UNDERCARRIAGE - 6'-7 long with adjustable skirt rubber - Galvanized bolt-on extensions - Adjustable surge knock back plate in front of feedboot BELT - 2-Ply equivalent (European style) - Self- adjusting polyurethane teardrop belt scraper Maximum stockpiling capacity (180 degrees): 6500 cu.yd Maximum height (at 27 degrees): TRANSPORT DIMENSIONS - Height: 8'-4 - Length: 38'-1 - Width: 7'-5 - Weight: 24,500 lbs __________ Tags: NewEq HB HPR000Z77T4H
