Kobelco 7065
不含增值稅價格
列印
INFO
產品類別
履帶式起重機
品牌/ 型號
Kobelco 7065
出廠年份
1996
國家
中國
一般級別
1
2
3
4
5
Mascus產品ID碼
AE3E6756
定價
幣別選擇
詳細資料
內部庫存號
1
吊臂種類
桁架
最新檢驗紀錄
2025-10-09
出廠年份/序號
1
前擁有者數量
1
總重
692000 kg 公斤
最大舉升能力
65000 kg 公斤
註冊編號
1
吊臂末端最大揚程能力
25000 kg 公斤
吊臂長度
43 m 公尺
排放級數
Stage V
最小懸臂長度
3 m 公尺
仰臂
15 m 公尺
起重機吊臂長度
15 m 公尺
最大舉升高度
54.9 m 公尺
起重機吊鉤高度- 水平臂
14 m 公尺
起重機吊鉤高度- 仰臂
14 m 公尺
起重機類型
固定臂
出廠顏色
Original
發動機制造商
Kobelco
載架類型
履帶式
狀況/保固
Good
前輪胎剩餘量
98
生產國
日本
交貨條件
FCA, FOB, CIF, EXW
認證
EPA, CE
附屬裝置
Fly Jib
Hook
Counter Weight
We're from Shanghai Jipan Trade Co.,Ltd.I'm the Sales Manager, specializing in selling used machines from various brands, including excavators,truck cranes,crawler cranes,and so on.With extensive export experience, our machines are sold well in Europe, America, Africa,and other regions, receiving rave reviews and a high repurchase rate.
We uphold the principles of integrity and quality, and have a professional service team to provide you with one-stop service, ensuring accurate, efficient, and safe delivery of your machines.We are committed to building long-term relationships with every customer from around the world with competitive prices and superior quality.
Contact: Jason
WhatsApp/Mobile:0086 13675656717
WeChat:+86 13675656717
Shipping Method:Container Vessel, Bulk Carrier, Flatbed Vessel, or RoRo Vessel.
配件
吊鉤組
其他資料
Basic parameters
Rated lifting capacity:65 tons
Working weight:64.6-69.2 tons
Engine: Equipped with a Mitsubishi 6D24-TE-1 engine, it has a power output of 169kW (230ps) and a rotational speed of 1800rpm.
Crane boom parameters
Main arm length: It can be configured between 9.1 meters and 54.9 meters, composed of arm sections of 3.0 meters,6.1 meters and 9.1 meters
The length of the auxiliary arm is available in three options:6.1 meters,12.2 meters, and 18.3 meters. The installation angles of the auxiliary arm are 10° and 30°
Working performance parameters
Maximum lifting moment: At a radius of 4.1 meters, the maximum rated lifting capacity can reach 65 tons.
Lifting speed: The wire rope speed of the main and auxiliary winches can reach 100 meters per minute.
Rotational speed: Free rotational speed is 3.5rpm, and braking rotational speed is 1.5rpm.
Walking speed: Ranging from 1.75 to 1.1km/h
Climbing ability: Up to 40% at most
Ground pressure:74-79kPa
Parameters of the hoisting system
Rated tensile force: Up to 167kN at most
Wire rope specification: The standard configuration for the main and auxiliary winches is 22mm wire rope
Hook configuration:Supports multiple hook configurations, including 65t (5-pulley), 45t, 32t, 19t and 6.6t ball head hooks
Safety devices:Optional safety equipment such as wind speed alarm and anti-overwinding device are available
